| Edge thickness | 0.4~3mm |
| Feed speed | 18m/min |
| Panel thickness | 10-50mm |
| Panel length | ≥140mm |
| Panel width | ≥50mm |
| Glue motor power | 0.37kw |
| Glue tank heating power | 1.5kw |
| Fine trimming motor power | 0.75 kw*2 @ 18000rpm |
| Buffing motor power | 0.18 kw*2 @ 1400rpm |
| Total motor power | 5.0 kw |
| Working pressure | 0.7Mpa |
| Extended support | 550mm |
| Outline size | 2370*850*1460mm |
| Package size | 2440*950*1630mm/3.78cbm |
| Net weight/Gross weight | 850kgs/985kgs |
