This cnc panel saw can be used on various of different materials : MDF, particalboard, plywood, solid wood, PVC, Acrylic, ABS, aluminum etc.

1. The machine equipped with air floating work table, easy to load the materials.
2.All PLC control, easy and simple operation. Equipped with Optimized software, can be directly imported material listing, optimized cutting and printing labels.
3.There is a fault alarm device,machine will stop at once when it work failure and have the function of fault detection,easy to check the cause of the problem.
4.Machine use international famous electric components from Japan, to ensure stability and high accuracy.


Model MJ150B MJ260B MJ330B MJ380B
Max. Cutting length 1500mm 2600mm 3200mm 3800mm
Max. Cutting thickness 75mm 75mm 75mm 75mm
Diameter of main saw blade 355mm 355mm 355mm 355mm
Diameter of main saw spindle 60mm 60mm 60mm 60mm
Rotation speed of main saw blade 5600r/min 5600r/min 5600r/min 5600r/min
Diameter of scoring saw blade 160/180mm 160/180mm 160/180mm 160/180mm
Rotation speed of scoring saw blade 6100r/min 6100r/min 6100r/min 6100r/min
Cutting speed 0-60m/min 0-60m/min 0-60m/min 0-60m/min
Main saw power 9kw 9kw 11kw 11kw
Guide rail Linear guide rail Linear guide rail Linear guide rail Linear guide rail
Scoring saw power 1.5kw 1.5kw 1.5kw 1.5kw
Feeding motor power 1.1kw 1.1kw 1.1kw 1.1kw
Total power 13kw 13kw 15kw 15kw
Table height from floor 900mm 900mm 900mm 900mm
Net weight 3000kg 4000kg 5500kg 6000kg
Dimension 4050*4000*1650 mm 5200*5300*1750 mm 6000*5300*1750 mm 6350*6450*1750 mm
