| 1 |
Max. Engraving area |
1300*2500*200mm |
| 2 |
Acceptable material thickness |
20mm |
| 3 |
Working table |
Vacuum combined working table 24 holes |
| 4 |
Vacuum pump |
7.5kw Water vacuum pump |
| 5 |
Working table size |
2500*1300mm |
| 6 |
Processing resolution |
±0.03mm |
| 7 |
Reposition resolution |
±0.02mm |
| 8 |
Max. Travelling speed |
40000mm/min |
| 9 |
Max. Working speed |
15000mm/min |
| 10 |
Spindle motor |
6.0kw Air cooling spindle |
| 11 |
Spindle rotating speed |
24000rpm |
| 12 |
Transmitting system |
X/Y axis gear rack+linear guide; Z axis ball screw+Square guide+Cylinder |
| 13 |
Driving motor |
Servo motor |
| 14 |
Drivers |
LEADSHINE |
| 15 |
Controlling system |
SYNTEC |
| 16 |
Voltage |
380V/50HZ/3P |
| 17 |
Surroundings |
Temperature: 0-45 degree; humidity: 30%-75% |
| 18 |
Weight |
2500kgs |
| 19 |
Dimension |
3650*2000*2020mm |
